| Window Dimensions | |
| Window Height(Max) | 2400mm |
| Sash Height & Width | 55mm/28mm |
| Interlocking Visible Face Width | |
| Slim Interlock | 20mm |
| Non Slim Interlock | 55mm |
| Track Option & Depth | |
| 2 Track depth | 74mm(Top Bottom)/78mm(Vertical) |
| 2 Track height | 46mm(Top Bottom)/22mm(Vertical) |
| 3 Track depth | 109mm(Top Bottom)/113mm(Vertical) |
| 3 Track height | 46mm(Top Bottom)/22mm(Vertical) |
| Corner Joint | |
| Track Joint | 90 Degree |
| Sash Joint | 90 Degree |
| Glass Range | |
| Single Glass Sash | 6mm to 8mm |
| Double Glass Sash | 16mm to 18mm |
| Roller Weight Capacity (2Pcs.) | |
| From 60kg to 160kg per shutter | |
NOTE: 16-18mm glass possible if quantity is more than 20 sliders. Mullion in mesh shutter is not possible.
