Window Dimensions | |
Window Height(Max) | 3650mm |
Sash Height & Width | 67mm/49mm |
Interlocking Visible Face Width | |
Slim Interlock | 25mm |
Track Option & Depth | |
2 Track depth | 120mm(Top Bottom)/125mm(Vertical) |
2 Track height | 42mm(Top Bottom)/23mm(Vertical) |
3 Track depth | 185mm(Top Bottom)/190mm(Vertical) |
3 Track height | 42mm(Top Bottom)/23mm(Vertical) |
Corner Joint | |
Track Joint | 90 Degree |
Sash Joint | 90 Degree |
Glass Range | |
Double Glass Sash | 26-36mm/11mm to 18mm |
Roller Weight Capacity (2Pcs.) | |
From 300kg to 500kg per shutter | 45 Degree |
NOTE: More than 300 kg per shutter is possible if quantity is more than 20 sliders.
