LOCKING TYPE: Euro Groove Multipoint
Clear View LT 22mm Minimal Sliding
Window Dimensions | |
Window Height(Max) | 4500mm |
Visible Face Height | |
Top/Bottom Track with Shutter | 50mm |
Vertical track With Shutter | 55mm |
Slim Interlock | 18mm |
Track Option & Depth | |
2 Track Top/Bottom Depth & Visible Height | 175mmx50mm |
2 Track Vertical Depth & Visible Height | 175mmx22mm |
3 Track Top/Bottom Depth & Visible Height | 262mmx50mm |
3 Track Vertical Depth & Visible Height | 262mmx22mm |
Corner Joint | |
Track Joint | 90 Degree |
Sash Joint | 90 Degree |
Glass Range | |
8mm to 32mm | |
Roller Weight Capacity (2Pcs.) | |
Upto 320kg per shutter | |
